VLSI Fundamentals: A Practical Approach Education Kit

Teaching materials now available on GitHub.

You can download the materials by clicking the button below which will take you to Arm Education's official GitHub pages.


Teach the fundamentals of Very Large-Scale Integration (VLSI), including how the theories and concepts can be applied in the design of simple logic circuits and in the physical implementation of a simplified microprocessor.



Kit specification:


  • Summary: A full set of 20 modules with lecture slides and lab exercises (in selected modules) ready for use in a typical 10-12-week undergraduate course (see full syllabus).
  • Modular and Flexible Use: Teaching staff have the freedom to choose which modules to teach – use all the modules in the Education Kit or only those that are most appropriate to your teaching outcomes.
  • Additional libraries for lab exercises are available for request here.
  • Prerequisites: Students are required to have an understanding of digital electronics and the basics of hardware description language (Verilog).

Course aim

To produce students with solid introductory knowledge on VLSI concepts and application of these concepts in simulation, verification, and physical implementation of a simplified microprocessor using standard industry tools.



Learning outcomes

  • Knowledge and understanding of
    • The characteristics of the nonideal transistor due to high field effects, channel length modulation, threshold voltage effects and leakage
    • How to estimate the characteristics of CMOS circuits including noise margins, DC response and RC delay models.
    • How to estimate the resistance and capacitance of on-chip wires and describe methods to optimize wire delay, power consumption and crosstalk in on-chip wires.
    • The operation of CMOS latches and flip-flops and plan cell layouts using stick diagrams.
    • The limits imposed by timing constraints such as setup and hold time, propagation and contamination delays in sequential circuits.
    • The importance of testing in chip design and the concepts of stuck-at fault, Automatic Test Pattern Generation, Built in Self Test.
    • The different SRAM architecture.
    • The sources of power dissipation in a circuit and methods to control power losses.
    • The implications of clock distribution networks on skew and clock power consumption.
    • The sources and effects of on-chip variation.
    • How to simulate a circuit using Simulation Program with Integrated Circuit Emphasis (SPICE) to determine its DC transfer characteristics, Transient response and Power consumption.



  • Intellectual
    • Outline the key characteristics/features of nMOS and pMOS transistors and draw the cross section of a CMOS inverter.
    • Use plots and cross section diagrams to describe the current and voltage (I-V) characteristics of the MOS device when operating in cut off, linear and saturation regions.
    • Describe the effects of technology scaling on the number and cost of transistors power dissipation in devices.
    • Explain logical effort and show how it can be applied in minimizing the delay of a combinational circuit path.
    • Explain and demonstrate techniques used to optimize combinational logic circuits for best critical paths and best delay/power trade-offs for logic gates.
    • Describe and explain the features of different adder architectures including: Carry-Ripple Adder, Carry-Skip Adder, Carry-Lookahead Adder, Carry-Select Adder, Carry-Increment Adder and Tree Adder.
    • Design and describe the operation of data path circuits such as comparators, shifters, multi-input adders and multipliers.
    • Describe the operation of Electrostatic discharge (ESD) protection circuits using their circuit diagram.
    • Describe the implementation of a simplified processor at abstraction levels including: Architecture, Microarchitecture, Logic Design, Circuit Design, Physical Design, Verification & Test.



  • Practical
    • Design, implement, simulate, and verify simple logic gates from transistor level schematic to layout.
    • Use NC-Verilog to simulate and verify the operation of logic blocks.
    • Use design compiler to synthesize logic gates from hardware description language and use SOC Encounter to place and route logic design.
    • Assemble a chip from schematic, layout, add pad frame and then tape out in GDSII format.



Syllabus

1 Introduction to VLSI
2 Circuits and Layout
3 Processor Example
4 CMOS Transistor Theory
5 Nonideal Transistor Theory
6 DC & Transient Response
7 Logical Effort
8 Power
9 Scaling
10 Simulation
11 Combinational Circuit Design
12 Sequential Circuit Design
13 Wires
14 Adders
15 Datapath Functional Units
16 SRAM
17 Clocking
18 Variation & Reliability
19 Test
20 Packaging, I/O & Power Distribution
